This is a manual antenna tuner that is capable of accepting up to 300 watts of transmitter power, and it can be used to tune dipole, vertical, mobile whip, long wire and other types of antenna on the 160 - 6 meter amateur bands.
It has a cross meter that is capable of measuring forward power, reflected power and standing wave ratio (SWR) concurrently.
The meter scale is illuminated, allowing easier viewing of the meter during low-light conditions (external DC power required)
Specifications:
- Frequency range: 1-8 - 50 MHz
- Input Impedance: 50 Ohms
- Maximum transit power: 300 watts or lower (SSB)
- Lighting power supply: DC 11v -15 v approx. 250 mA
- Bands: 11 Bands
- Output Impedance: 10-600 ohms
- Minumum SWR measurement power: 6 watts
- Weight: 6 lbs.
- Dimensions: 10 x 4 x 8 Inches
Notes:
Tuner should be adjusted to minimum SWR using 10W RF, before applying full power.
NatCommGroup products (Comet, Daiwa, Maldol, Create, Lido, and NCG brands) are under factory warranty for one year from date of purchase.
